項目規格參數相對孔徑 (F No.)2.2焦距(Focal-Length)1.47mm光學后焦 (Optical Back Focal Length)1.55mm機械后焦(Flange Back Focal Length）0.95mm最大像面大小（MAX Image circle)?3.3鏡片構成（Lens structure)4P接口 (Mount )M5*0.2P視場角(FOV )Senso
| 項目 | 規格參數 | |||
| 相對孔徑 (F No.) | 2.2 | |||
| 焦距(Focal-Length) | 1.47mm | |||
| 光學后焦 (Optical Back Focal Length) | 1.55mm | |||
| 機械后焦(Flange Back Focal Length） | 0.95mm | |||
| 最大像面大小（MAX Image circle) | ?3.3 | |||
| 鏡片構成（Lens structure) | 4P | |||
| 接口 (Mount ) | M5*0.2P | |||
| 視場角(FOV ) | Sensor | D(對角)° | H(水平)° | V(垂直)° |
| 1/6 | 91 | 78 | 63 | |
| 畸變（Distortion) | <1% | |||
| 相對亮度（Relative illumination) | >48% | |||
| 最大主光線夾角（CRA) | <35° | |||
| 光學總長（Total Length) | 4.5mm | |||
| 操作溫度 (Operating temperature) | -20℃~+70℃ | |||
| IP防護等級：IP0 | Tavg>=88% @420-600nm | T=50% @650±10nm | Tavg<=5% @700-1050nm | |
| 尺寸圖 |
| |||
